PVC Hose

PVC Reinforced Hose

PVC Reinforced Hose is a durable and flexible hose designed for liquid transfer in industrial, agricultural, and construction applications. Its embedded plastic rib reinforcement provides strength and prevents collapse under suction.

ID 4495 Images

Back to Line Request Quote

Description

The hose features a clear PVC body with integrated spiral or helical ribs that enhance structural integrity. The plastic reinforcement ensures the hose maintains shape and flow, even under vacuum or bending stress. Lightweight, abrasion-resistant, and flexible, it is ideal for water, light chemicals, and general industrial liquid transfer. The transparency allows visual monitoring of fluid flow.

Specification

Features

• Embedded plastic ribs prevent hose collapse and maintain shape
• Flexible and lightweight for easy handling
• Transparent design for fluid monitoring
• Resistant to abrasion and moderate pressure
• Suitable for industrial, agricultural, and construction liquid transfer

Technical

• Material: PVC with plastic rib reinforcement
• Temperature Range: -10°C to 60°C (14°F to 140°F)
• Working Pressure: Up to 3 bar
• Hose Diameter Range: 6mm – 100mm
• Bend Radius: Approx. 2 × hose diameter
• Operating Environment: Indoor/outdoor, suitable for water, light chemicals, and industrial fluids
