Chemical Composite Hose

Chemical Composite Hose is a high-performance flexible hose designed for safe and efficient transfer of aggressive chemicals, acids, and corrosive liquids. Engineered for industrial and chemical processing applications, it combines excellent chemical resistance with mechanical strength and flexibility.

ID 33211 Images

Back to Line Request Quote

Description

This hose features a PTFE inner liner, providing outstanding resistance to corrosion, chemical attack, and high temperatures. The hose is reinforced with stainless steel wire braids and spirals for superior pressure resistance and mechanical durability. Its smooth bore ensures minimal flow resistance and prevents contamination. Suitable for chemical plants, industrial fluid transfer, and laboratory applications.

Specification

Features

• Inner PTFE liner with excellent chemical and corrosion resistance
• Stainless steel wire reinforcement for high-pressure capability and durability
• Flexible design for easy handling and installation
• Smooth bore minimizes flow resistance and contamination
• Suitable for industrial, chemical, and laboratory fluid transfer applications

Technical

Stretch rate: ≤10%
Maximum working pressure: 16 bar
Test pressure: 15 times maximum working pressure
Burst pressure: ≥4 times maximum working pressure
Negative pressure: ≤0.9 bar
Twisting degree: ≤10%
Resistivity: ≤2 ohms/m (for diameters <100 mm)
Operating temperature: -30°C to 80°C
